Emergency LED driver for Non Dimmable outdoor Light
|
18490X-1-HB
•
Emergency operation of LED light source and luminaires, for both factory and field installation
•
Perfectly compatible with non dimmable LED UFO, High Bay luminaires
•
Constant emergency power output, wide range of output voltage from 10 to 300VDC, output current auto adjustable
•
Auto test function reduces the maintenance cost
•
IP67 rating. Suitable for outdoor and wet applications
Type #
Emergency Power & Output Voltage
184901-1-HB
9W, 10-300VDC
|
Downloads
|
Product Specs
| Type | 184901-1-HB |
| Lamp type | LED High-bay or UFO luminaire |
| Rated voltage | 120-277VAC 50/60Hz |
| Rated current | 0.04A |
| Rated power | 3W |
| Emergency output power | 9W |
| Output voltage | 10-300VDC |
| Output current of AC driver | 3A (Max.) |
| Operation frequency | 320kHz≥f≥50kHz |
| Power factor | 0.5 |
| Battery | Li-ion |
| Charging time | 24 Hours |
| Discharge time | >90 Minutes |
| Life time | 5 Years |
| Charging current | 0.17A |
| Charging cycles | >1000 |
| Operation temperature | 0-50℃ (32°F-122°F) |
| Efficiency | 80% |
| Abnormal protection | Over load, over current, inrush, over voltage, over temperature, charging and discharging, open circuit, short circuit protection with auto reset |
| Wire | 0.75-1.5mm² |
| EMC& FCC IC standard | EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3; FCC part 15; ICES-005 |
| Safety standard | EN 61347-1, EN 61347-2-7, UL924, CSA C.22.2 No. 141 |
| Meas. mm [inch] | L441.2 [13.37] x W40 [1.57] x H40 [1.57] |
